Configuration Reference

About 1197 wordsAbout 4 min

2025-08-25

This page lists all configuration keys, their defaults, and effects. Sources: flags, environment (TKA_ prefix), or config files (config.yaml).

Conventions

Env var mapping replaces . with _ and uppercases keys, prefixed with TKA_ (e.g., tailscale.hostname → TKA_TAILSCALE_HOSTNAME).
Default config search paths: ., $HOME/.config/tka/, /etc/tka/.

Common

debug (bool, default false)
- Enable debug logging.
otel.endpoint (string, default "")
- OTLP gRPC endpoint; if empty, OTel spans/metrics exporters may be disabled.
otel.insecure (bool, default true)
- Whether to use insecure transport to the OTLP endpoint.

Tailscale

tailscale.hostname (string, default tka)
- Hostname for the tsnet node; also used by the CLI to build https://{hostname}.{tailnet}.
tailscale.port (int, default 443)
- API port. Scheme is https if 443, otherwise http.
tailscale.stateDir (string, default "")
- Directory for tsnet state (keys, control data).
- If empty, a directory is selected automatically under os.UserConfigDir based on the name of the binary.
tailscale.tailnet (string, no default)
- Tailnet domain, e.g., example.ts.net; used by CLI to compose the base URL.
tailscale.capName (string, default specht-labs.de/cap/tka)
- Capability name the server requires from Tailscale ACLs.

Tailscale Environment variables

TS_AUTHKEY
- Auth key used to register/login the node to your tailnet without an interactive browser flow.
- Recommended to use an ephemeral/reusable auth key generated from the Tailscale admin console.
- Example: export TS_AUTHKEY=tskey-auth-XXXXXXXXXXXXXXXX
- Security: treat like a secret. Prefer short-lived keys.
TSNET_FORCE_LOGIN
- If set to 1, true, or TRUE, forces an interactive/browser login even if an auth key is present.
- Useful for developer setups where you don’t want to depend on an auth key.
- Example: export TSNET_FORCE_LOGIN=1

Notes:

TKA embeds Tailscale using tsnet. These variables are read by Tailscale when bringing the embedded node up; TKA itself does not parse them.
Variables commonly used with the standalone tailscaled daemon (e.g., TS_STATE_DIR, TAILSCALE_*) do not apply to the embedded tsnet client in this binary. Use tailscale.stateDir in TKA config or --dir to control state location.

Server HTTP timeouts

server.readTimeout (duration, default 10s)
server.readHeaderTimeout (duration, default 5s)
server.writeTimeout (duration, default 20s)
server.idleTimeout (duration, default 120s)

These tune the embedded HTTP server created for tsnet.

Operator

Defaults from code: namespace=tka-dev, clusterName=tka-cluster, contextPrefix=tka-context-, userPrefix=tka-user-.

operator.namespace (string)
- Namespace where SignIn and ServiceAccounts/Bindings are created.
operator.clusterName (string)
- Name written into kubeconfig contexts.
operator.contextPrefix (string)
- Prefix for per-user kubeconfig context name.
operator.userPrefix (string)
- Prefix for kubeconfig user entry.

API behavior

api.retryAfterSeconds (int, default 1)
- Hint for clients polling async operations (e.g., kubeconfig provisioning).

CLI Output Settings

These settings control how the TKA CLI displays information and are used by client commands:

output.theme (string, default tokyo-night)
- Color theme for CLI output. Available themes: ascii, dark, dracula, light, markdown, notty, tokyo-night
output.long (bool, default true)
- Show detailed output by default when available
output.quiet (bool, default false)
- Suppress non-essential output when available
output.markdownlint-fix (bool, default false)
- Apply markdown formatting fixes to generated documentation

The clusterInfo section configures the cluster connection details that TKA exposes to authenticated users through the cluster-info API endpoint. This information is used by users to configure their kubeconfig files and understand the cluster they're connecting to.

clusterInfo.apiEndpoint (string, required unless configMapRef.enabled is true)
- The Kubernetes API server URL or IP address that users should connect to
- This should be the externally accessible endpoint of the cluster's API server
- Examples: "https://api.cluster.example.com:6443", "https://192.168.1.100:6443"
- Note: Must be set for TKA to start when not using configMapRef.
clusterInfo.caData (string, base64-encoded, default "")
- The base64-encoded Certificate Authority (CA) data for the Kubernetes cluster
- Used to verify the TLS certificate presented by the API server
- Should be the PEM-encoded CA certificate, encoded as base64
- If empty and insecureSkipTLSVerify is false, the system's root CA bundle will be used
- Note: CA data is public information (not sensitive) and can be stored in ConfigMaps
- Source: Available from cluster-info ConfigMap in kube-public namespace or kubeconfig
- Purpose: Required for production clusters to verify server identity
clusterInfo.insecureSkipTLSVerify (bool, default false)
- Controls whether TLS certificate verification should be skipped when connecting to the cluster
- When true, clients will accept any certificate and ignore hostname mismatches
- Security: Should only be set to true for development/testing with self-signed certificates
- Production clusters should use valid certificates and keep this false
clusterInfo.labels (map[string]string, default {})
- Key-value pairs used to identify and categorize the cluster
- Helps users distinguish between different clusters and can be used for automation
- Common examples: environment: production, region: us-west-2, project: webapp, team: platform
- These labels are exposed in the cluster-info API response and can be used by client tools

ConfigMap Reference

Use a Kubernetes ConfigMap to supply cluster connection details. This is useful for kubeadm clusters which expose a cluster-info ConfigMap in the kube-public namespace.

clusterInfo.configMapRef.enabled (bool, default false)
- When true, TKA reads connection details from the specified ConfigMap
- Mutually exclusive with explicit clusterInfo.* connection settings
clusterInfo.configMapRef.name (string, default "")
- Name of the ConfigMap containing connection details
clusterInfo.configMapRef.namespace (string, default "")
- Namespace where the ConfigMap is located
clusterInfo.configMapRef.keys.apiEndpoint (string, default "apiEndpoint")
- Key within the ConfigMap data which contains the API endpoint
clusterInfo.configMapRef.keys.caData (string, default "caData")
- Key within the ConfigMap data which contains base64-encoded CA certificate data
clusterInfo.configMapRef.keys.insecure (string, default "insecure")
- Key within the ConfigMap data which contains a boolean-like string for insecure TLS (e.g., "true", "1")
clusterInfo.configMapRef.keys.kubeconfig (string, default "kubeconfig")
- Optional. If set and present, TKA will parse the embedded kubeconfig and extract the first cluster's server and certificate-authority-data (kubeadm cluster-info style).
Use clusterInfo.labels to add labels; they apply in both explicit and ConfigMap modes

Note

You must provide exactly one of: explicit clusterInfo.apiEndpoint or configMapRef.enabled: true with a valid reference. If both are provided, TKA will refuse to start.

Flags

Server and CLI share some flags via the root command:

--config, -c            Path to config file
--debug                 Enable debug logging (maps to debug)
--server, -s            Tailscale hostname (maps to tailscale.hostname)
--port, -p              API port (HTTP) (maps to tailscale.port)

Server-only flags:

--dir, -d               tsnet state directory (maps to tailscale.stateDir)
--cap-name, -n          Capability name to require (maps to tailscale.capName)
--health-port           Port for local metrics and health server (maps to health.port)
--api-endpoint          Kubernetes API endpoint URL (maps to clusterInfo.apiEndpoint)
--ca-data               Base64-encoded cluster CA data (maps to clusterInfo.caData)
--insecure-skip-tls-verify  Skip TLS verification (maps to clusterInfo.insecureSkipTLSVerify)
--labels                Cluster labels key=value list (maps to clusterInfo.labels)

Example config.yaml

# Enable debug logging (top-level, not under server)
debug: false

# CLI output settings
output:
  theme: tokyo-night
  long: true
  quiet: false
  markdownlint-fix: false

tailscale:
  hostname: tka
  port: 443
  stateDir: /var/lib/tka/tsnet-state
  tailnet: your-tailnet.ts.net
  capName: specht-labs.de/cap/tka

server:
  readTimeout: 10s
  readHeaderTimeout: 5s
  writeTimeout: 20s
  idleTimeout: 120s

otel:
  endpoint: ""
  insecure: true

operator:
  namespace: tka-system
  clusterName: tka-cluster
  contextPrefix: tka-context-
  userPrefix: tka-user-

api:
  retryAfterSeconds: 1

clusterInfo:
  labels:
    environment: production
    region: us-west-2
    project: webapp
    team: platform

  # Alternative: use a ConfigMap as the source of cluster connection details
  # Enable and omit apiEndpoint above.
  configMapRef:
    enabled: false
    name: "cluster-info"
    namespace: "kube-public"
    keys:
      apiEndpoint: "apiEndpoint"
      caData: "caData"
      insecure: "insecure"
